25mm Pillar Drill Machine

Name: 25mm Pillar Drill Machine
Brand: YOGI MACHINE TOOLS
Price: 90000 INR
Availability: InStock

90000 INR/Unit

Get a Price/Quote

Product Details:

Diameter 25 mm
Motor Power 1.1 kW
Condition New
Noise Level Low Noise Operation
Dimension (L*W*H) 900 mm x 500 mm x 1500 mm
Cutting Area 25 mm Diameter
Table Size 330 mm x 330 mm
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

25mm Pillar Drill Machine Price And Quantity

Price 90000 INR/Unit
Minimum Order Quantity 1 Unit

Drilling Capacity (in Steel) 20 mm
Distance from Table to Spindle Nose 675 mm
Distance from Base to Spindle Nose 900 mm
Chuck Size 13 mm
Base Size 580 mm x 400 mm
Distance from Spindle Axis to Column 250 mm
Spindle Travel 125 mm
Column Diameter 80 mm
V-Belt Size B 46
Drilling Capacity (in Cast Iron) 25 mm
No. of Spindle Speeds 8

25mm Pillar Drill Machine Product Specifications

Voltage 220V
Power Source Electric
Frequency 50 Hz
Automatic Grade Automatic
Color Green
Machine Type Pillar Type
Features Heavy Duty Construction, Adjustable Table Height, Accurate Drilling, Smooth Operation
Spindle Speed 480 - 3000 RPM (Variable)
Usage & Applications Drilling, reaming, and tapping operations on metals and other materials
Diameter 25 mm
Motor Power 1.1 kW
Condition New
Computerized No
Power 1.5 HP
Product Type Pillar Drill Machine
Noise Level Low Noise Operation
Dimension (L*W*H) 900 mm x 500 mm x 1500 mm
Cutting Area 25 mm Diameter
CNC Or Not No
Material Metal
Capacity 25 mm
Weight (kg) 120 kg
Table Size 330 mm x 330 mm

Drilling Capacity (in Steel) 20 mm
Distance from Table to Spindle Nose 675 mm
Distance from Base to Spindle Nose 900 mm
Chuck Size 13 mm
Base Size 580 mm x 400 mm
Distance from Spindle Axis to Column 250 mm
Spindle Travel 125 mm
Column Diameter 80 mm
V-Belt Size B 46
Drilling Capacity (in Cast Iron) 25 mm
No. of Spindle Speeds 8

25mm Pillar Drill Machine Trade Information

Payment Terms Cash in Advance (CID)
Supply Ability 10 Unit Per Month
Delivery Time 30 Days
Main Domestic Market All India

Product Description

Experience unbeatable performance and savings with our featured 25mm Pillar Drill Machine, engineered for both versatility and reliability. With an impressive 25 mm drilling capacity in cast iron, this redoubtable machine delivers valuable precision for drilling, reaming, and tapping in metals and other materials. Access 8 variable spindle speeds (130-2600 RPM), a robust 1.5 HP motor, and heavy-duty construction for smooth, low-noise operation. Its adjustable table height and accurate drilling features make it an indispensable asset for workshops seeking efficiency and durability.

Applications and Versatility of the 25mm Pillar Drill Machine

The 25mm Pillar Drill Machine is suitable for a wide array of industrial and workshop environments. Its primary area of application includes precision drilling, tapping, and reaming operations on steel, cast iron, and other metals. Ideal for manufacturing, maintenance, tool rooms, and fabrication shops, this machine is specifically designed for users requiring high accuracy and smooth operation. Its robust construction ensures dependable performance for both small batch work and continuous production runs.

Domestic Supply, Export Markets, and Delivery Process

This 25mm Pillar Drill Machine is in high demand across India's primary domestic markets and is frequently supplied to major export destinations including Asia, Africa, and the Middle East. With a reliable supply ability, customers can quickly receive quotations, complete the purchase process, and have machines handed over or delivered to their doorstep efficiently. Our export-ready approach allows for prompt and safe shipments to both local and international clients, ensuring your equipment arrives ready for use.

Specifications

Model	YPD-25
Machine Capacity (MM)	25 MM
Column Diameter (MM)	92 MM
Center of Spindle to Column (MM)	250 MM
Distance Spindle to Table (MM)	660 MM
Distance Spindle to Base (MM)	1045 MM
Distance from Spindle Centre to Column	250 (max)
Table Travel	480 MM
Spindle Nose	MT-3
Spindle Travel (MM)	180 MM
Range of Spindle Speed (RPM)	130-2600
No. of Spindle Speed	8

FAQ's of 25mm Pillar Drill Machine:

Q: How do I select the appropriate spindle speed for different materials?

A: You should adjust the spindle speed-eight speeds ranging from 130 to 2600 RPM-based on the hardness and type of material. Lower speeds are ideal for hard metals, while higher speeds suit softer materials.

Q: What is the process for receiving a quotation and placing an order?

A: Simply contact our sales team with your requirements. After you receive your quotation and confirm the specifications, the order can be processed, and the machine will soon be handed over or delivered to your location.

Q: Where can this 25mm Pillar Drill Machine be effectively used?

A: It is perfectly suited for workshops, fabrication shops, tool rooms, maintenance departments, and production facilities requiring precise metalworking operations like drilling, reaming, and tapping.

Q: What is the benefit of having an adjustable table height on this drill machine?

A: The adjustable table height allows you to work with various workpiece sizes and shapes, enhancing versatility and enabling precise positioning for accurate drilling operations.

Q: When can I expect delivery after placing an order?

A: Delivery timelines vary based on location and stock availability. For domestic orders in India, machines are typically delivered within a few days after order confirmation. Export orders are dispatched promptly as per agreement.
